Radar SART TBR-600C Taiyo

Radar SART TBR-600C Taiyo yang kami jual adalah produk baru dengan kualitas terbaik dan serta memiliki sertifikasi kelayakan.


TBR-600C is a SART conforming to the international standards for the GMDSS and has obtained is type approval by Japanese agencies and MED in charge. It is a handy radar transponder in the 9GHz radar band with transmits reply signals sycnhronizing to radar hits (interrogation) from radar on SART craft. The reply, a TBR-600C SART signal, when received by the TBR-600C SART on the radar scope of the SAR craft.

Thus, a TBR-600C SART helps to make SAR operation very efficient, especially, at nigh, in bad weather or inthe poor visibility.


Contact us


Radar SART TBR-600C Taiyo details:



  • Frequency: From 9200MHz to 9500MHz
  • Polarization: Horizontal


  • Vertical Beam Width: ±12.5 degrees
  • Horizontal: 360 degrees (Omni directional)


  • Effective Receiver Sensitivity(ERS): Better than -50dBm
  • Recovery Time: 10µs


  • Modulation Method: Q0N(Pulse Modulation)
  • Form of Sweep: Saw Tooth
  • Forward of Sweep Tiqme: 7.5±1.0µs
  • Return Sweep Time: 0.4±0.1µs
  • Response Signal: 12 Sweeps
  • Power(EIRP): Not less than 400mW (+26 dBm)
  • Delay: 05µs or less


  • Battery Type: Lithium Non-Rechargeable Sealed Baterry
  • Nominal Voltage: 6V
  • Capacity: Stand-by condition minimum 96 hours, Transmission 8 hours
  • Validity Period: 3 Years after replacing the battery

Temperature Range

  • Stowage: -30°C~+70°C
  • Ambient: -20°C~+55°C

Physical Characteristics (Main Unit)

  • Size: 309x Φ 88mm
  • Weight: Approx.600g


Produk Radar SART TBR-600C Taiyo ini juga tersedia di Batam – Jakarta – Samarinda – Surabaya – China
