Weather Fax AWFAX-100 di Batam

Weather Fax AWFAX-100 yang kami jual adalah produk baru dengan kualitas terbaik dan serta memiliki sertifikasi.


Programmed with all existing facsimile stations and frequencies. User may also program channels and edit existing channels.

Clear-cup weather charts and satellite images in 16 gray levels display on 15 inch LCD.

Store max 200 weather charts

Automatic channel selection by judging the quality of signal reception

All 150 standard facsimile channels in 2-25MHz are pre-programmed and additional 300 channels can be added.

Boot full automatically receive, unattended

Clear-cup charts bt excellent mid-frequency

Selectivity and receiver sensitivity

Friendly user interface ensure easy to learn and operation convenience

High performance CPU insure good user experience

Print or store weather images through two USB interface

Contact us


Weather Fax AWFAX-100 details:


  • System Architecture: twice-conversion low-IF architecture
  • Frequency range: MF/HF2.0000-24.9999MHz
  • Received signal format F3C
  • Channels: 150 channels have been set, you can add 300 channels
  • Image rojection ratio: Bettor than 60dB
  • Sensitivity: 2 µV (+6dB µ) or less at 20dB SINAD or  -120dBm
  • IF Selectivity: 6dB down point 2.4KHz to 3.0KHz or 66dB down poitn 6KHz or less
  • Selectivity: Better tha 2.0KHz (-6dB)
  • Display: 15″ LCD Display
  • Resolution: 1024 x 768 pixels
  • The Number of Storage Weather Map: Max Store 200 Images Data
  • Printer Type: 36 Printer Mode
  • Printer Mode: Automatic or Manual
  • Weather Map Output Mode: U disk or HP printer
  • Cooperation Factor: 576/288
  • Receive Rate: 60/90/120/240 scan per minute
  • Gray Rating: 16 tones
  • Scanning Line Density: Approx. 7 lines/mm, 3.5 lines/mm
  • Phase Matching: Automatic or Manual
  • Input Voltage: 12-48 VDC DC power supply
  • Power Consumption: Less than or equal to 30 watts
  • Working Environment: Temperature: 0 °C to 50 °C
  • Humidity: 95% Rh (35 °C, 4 hours)
  • Size and Weight: Length 354 x width 278 x height 100 mm


Produk Weather Fax AWFAX-100 ini tersedia di Batam, Jakarta, Samarinda,  Surabaya, China.
